Electrical Power
1. Plug the provided power cord into the Main Power Input.
Then plug the power cord into the proper voltage power
source.
2. Turn the Main Power Switch to ON and the unit will start
heating up. The temperature display will indicate the current
heater temperature in degrees Celsius.
3. The unit will take approximately 20 minutes to reach the
operating temperature of 407ºC. The unit will not produce
aerosol unless the temperature is in the operating range.
Warning – Burn Hazard
Severe burns may occur if in contact with the output collar.
Caution – Hot Surfaces
The output collar at the back of the unit may be
and
dangerous if in contact with flammable objects.
Aerosol Generation
1. At the inert gas source, adjust the gas regulator to 50 psi
(3.45 Bar), ± 5 psi (0.35 Bar). Turn on the compressed gas at
the source. Gas should be flowing through the unit and out of
the outlet nozzle at the back of the generator.
2. Turn the Aerosol Switch to ON.
3. Fully turn the metering valve knob counterclockwise. After
approximately 10 seconds the unit will start producing aerosol
at maximum concentration.
4. Adjust the desired level of concentration by turning the
metering valve knob clockwise for less concentration and
counterclockwise for more concentration.
Note
When the aerosol starts the temperature display will drop and
then rise slowly. This is normal.
