30 1800296 C
Table 2 Replacement Fuses
For 115 V Generator
Part Numbers 9300207
and 9300213
Use ATI Part Number 6400112
(5 X 20 mm, 8A, 250V, FAST BLO)
For 230 V Generator
Part Numbers 9300208
and 9300214
Use ATI Part Number 6400111
(5 X 20 mm, 4A, 250 V, FAST BLO)
4. Replace the fuse holder by gently inserting it back into the
Main Power Input until the tabs snap back into their original
location.
5. Close the fuse cover.
6. Verify the correct voltage is displayed in the fuse cover
window.
Note
Incorrect fuse replacement may damage internal components of
the generator.
