Line Function Setting range
or display
Setting
increment
Basic
setting
Inputs / outputs test
7700 I Relay test No test
This consists of instructing the regulator's relays one by one and checking their outputs. This enables you to check that
the relays are working and that the cabling is correct. Check that each appliance in the installation is operating correctly.
(0) No test, (1) Everything is on STOP, (2) Relay output QX1 : heat pump CC1 (if 1 circuit ) or heat pump CC2 (if 2 circuits),
(3) Relay output QX2 : Electrical back-up (1st stage) or Boiler connection distribution valve, (4) Relay output QX3 : Electrical
back-up (2nd stage) or Boiler connection contact, (5) Relay output QX4 : DHW distribution valve, (6) Relay output QX5 :
DHW Electrical back-up, (7) Relay output QX6 , (8) Relay output QX31 : Heat circ mix valve open Y1 (or control pilot-wire),
(9) Relay output QX32 : Heat circ mix valve close Y2, (10) Relay output QX33 : heat pump CC1 if 2 circuits (mixed circuit, the less hot),
(11) Relay output QX34, (12) Relay output QX35 : Swimming pool distribution valve, (13) Relay output QX21 module 1,
(14) Relay output QX22 module 1, (15) Relay output QX23 module 1, (16) Relay output QX21 module 2, (17) Relay output QX22
module 2, (18) Relay output QX23 module 2, (19) Not used, (20) Not used, (21) Not used.
The display shows the “Key” symbol. Pressing the Info button displays "Error 368".
Warning: The component being tested is receiving electrical power throughout the test.
7710 I Output UX1 test 0... 100% 1 --
7716 I Output UX2 test 0... 100% 1 --
7722 I Digital output DO2 Off, On Off
7723 I Heat pump D3 Off, On Off
7724 I Outputs test UX3 ("Inverter" command) 0... 100 % --
7725 I Voltage value (Ux3) 0... 10 v --
7804 I Sensor temperature BX1 (HP ow temperature) -28... 350 °C --
7805 I Sensor temperature BX2 (HP return temperature) -28... 350 °C --
7806 I Sensor temperature BX3 (DHW temperature) -28... 350 °C --
7807 I Sensor temperature BX4 (Outdoor temperature) -28... 350 °C --
7858 I Input signal H3
None, Closed (ooo), Open (---)
,
Pulse, Frequency Hz, Voltage V
None
7911 I Input EX1 (Power shedding, EJP) 0, 230 V --
7912 I Input EX2 (Tariffs day/night) 0, 230 V --
7913 I Input EX3 (External fault) 0, 230 V --
State
8000 I State heating circuit 1 --
8001 I State heating circuit 2 --
8003 I State DHW --
8004 I State cooling circuit 1 --
8006 I State heat pump --
8007 I State solar --
8010 I State buffer --
8011 I State swimming pool --
8022 I State supplementary source --
8025 I State cooling circuit 2 --
Installation and operation manual "1734 - EN" - 63 -
