Atlantic F620 - Installing the Appliance

24
EN
INSTALLING THE APPLIANCE
Unlocking the horizontal appliance locking tab
We recommend leaving the appliance in its protective blocks, and placing
it flat on the floor.
Fastening the locking tab
Use suitable screws and wall
plugs for your support (e.g.:
plasterboard).
Drilling
points B
Drilling
points A
Drilling
points A
Maintain the minimum distances
from furniture when positioning the
appliance.
Do not install shelves above vertical
appliances.
25
50
50
25
12
Wet area No electrical appliances
Medium-
wet area
IPX4 electrical appliances
Dimensions in cm
