7.4.9 Specific data of GA 150 psi 1)
Compressor GA11 GA15 GA18 GA22 GA30C
Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hz 60 60 60 60 60
Maximum (unloading) pressure
- Pack/Workplace . . . . . . . . . . . . . . . . . . . . . . . . . . . bar(e) 10.8 10.8 10.8 10.8 10.8
- Pack FF/Workplace FF . . . . . . . . . . . . . . . . . . . . . bar(e) 10.55 10.55 10.55 10.55 10.55
Nominal working pressure . . . . . . . . . . . . . . . . . . . . bar(e) 10.3 10.3 10.3 10.3 10.3
Power input
- Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . kW 14.5 19.9 24.0 28.5 37.6
- Workplace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . kW 14.9 20.4 24.4 28.9 37.6
- Pack FF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . kW 15.6 21.0 25.5 30.0 39.2
- Workplace FF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . kW 16.1 21.4 25.9 30.4 39.2
Temperature of air at outlet valve
- Pack/Workplace . . . . . . . . . . . . . . . . . . . . . . . . . . . C 25 25 26 26 27
- Pack FF/Workplace FF . . . . . . . . . . . . . . . . . . . . . C 20 20 23 23 23
Motor shaft speed . . . . . . . . . . . . . . . . . . . . . . . . . . . r/min 3545 3540 3550 3550 3560
Oil capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . l 6.7 7 7.5 8 11.1
Maximum sound pressure level 2)
- Workplace/Workplace FF . . . . . . . . . . . . . . . . . . . dB(A) 63 64 66 67 69
- Pack/Pack FF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . dB(A) 68 69 70 71 69
Pressure dewpoint, Pack FF/Workplace FF 3) . . . . . C 3 3 3 3 3
7.4.10 Specific data of GA 175 psi 1)
Compressor GA11 GA15 GA18 GA22 GA30C
Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hz 60 60 60 60 60
Maximum (unloading) pressure
- Pack/Workplace . . . . . . . . . . . . . . . . . . . . . . . . . . . bar(e) 12.5 12.5 12.5 12.5 12.5
- Pack FF/Workplace FF . . . . . . . . . . . . . . . . . . . . . bar(e) 12.25 12.25 12.25 12.25 12.25
Nominal working pressure . . . . . . . . . . . . . . . . . . . . bar(e) 12 12 12 12 12
Power input
- Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . kW 14.0 19.0 23.4 28.5 37.8
- Workplace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . kW 14.4 19.5 23.9 28.9 37.8
- Pack FF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . kW 15.1 20.1 24.9 30.0 39.4
- Workplace FF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . kW 15.5 20.5 25.3 30.4 39.4
Temperature of air at outlet valve
- Pack/Workplace . . . . . . . . . . . . . . . . . . . . . . . . . . . C 25 25 26 26 27
- Pack FF/Workplace FF . . . . . . . . . . . . . . . . . . . . . C 20 20 23 23 23
Motor shaft speed . . . . . . . . . . . . . . . . . . . . . . . . . . . r/min 3545 3540 3550 3550 3560
Oil capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . l 6.7 7 7.5 8 11.1
Maximum sound pressure level 2)
- Workplace/Workplace FF . . . . . . . . . . . . . . . . . . . dB(A) 63 64 66 67 69
- Pack/Pack FF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . dB(A) 68 69 70 71 69
Pressure dewpoint, Pack FF/Workplace FF 3) . . . . . C 3 3 3 3 3
