10.2 Critical bolt connections
Parts to assembly A Parts to assembly B Dimension Quality
Torqu e
(Nm)
Allowed
deviation
(Nm)
Additional
treatment
Applicable
standard
Lower rotation system (central
hole)
Base frame
M14 8.8
115
± 29
TEST
Lower rotation system Base frame
M10 8.8
48.2
± 5
AC - STD 4369
Mast - Rotatory system Lower rotation system
M8 8.8
24.3
± 5
AC - STD 4369
Upper rotation system Canopy / Lifting beam
M8 8.8
24.3 ± 5 AC - STD 4369
Friction plates Mast segments
M5 8.8
6 ± 0,5 AC - STD 4369
Fuel tank (plastic) Support
M10 8.8
7.5 ± 0 ROTOBASQUE STD
Support M6 Base frame
M6 8.8 10.1
± 1 AC - STD 4369
Support M8 Base frame
M8 8.8 24.3
± 2,5 AC - STD 4369
Lifting beam Base frame
M10 8.8 48,2
± 5
AC - STD 4369
Roof Lifting beam
M8 8.8 24.3 ± 2,5 AC - STD 4369
Engine Alternator flange
M10 8.8 25 Loctite 2107 LINZ STD
Engine Shock absorber
M10 8.8 16.8 LESOL STD
Engine support Floor
M10 8.8 48.2 ± 5 AC - STD 4369
Alternator Shock absorber
M10 8.8 16.8 AC - STD 4369
Alternator support Floor
M10 8.8 48.2 ± 5 AC - STD 4369
Floor Base frame
M10 8.8 48.2 ± 5 AC - STD 4369
Upper mast segment Mast head
M10 8.8 48.2 ± 5 AC - STD 4369
Mast head
LED floodlight support
M18 8.8 75 Loctite 2107 TEST
LED floodlight support LED floodlight
M10 8.8 20 TEST
Mast head
MH floodlight support
M12 8.8 45 Loctite 2107 TEST
MH floodlight support MH floodlight
M10 8.8 25 Loctite 2107 TEST
