Atlas Copco HiLight H5+ Hd ESF

- 87 -
10.5 Dimensions
SPANISH PLATE SUPPORT ( 1 : 15 )
A
R30.5
1460
1406
174 174
Lifting Point
Emergency Stop
Data Plate
Electrical
Power Outlet
1486
164 164306
662
Drain Point
Exhaust Outlet
65
67
Forklift
Forklift
640
640
65 1150 65
439
WHITE REFLECTOR
138
1012120
543.7
50
30
ORANGE REFLECTORS
(IN BOTH SIDES)
460.7
135
130
235
550
235
130
REAR LIGHTS
49
49
2504.4
35.5 1209.1 35.5
89.7
116.7
116.7
647 722.6
383.4
707
246
LIGHTING COMPONENTS
