- 20 -
DEPLOYMENT AND OPERATION
SELECTING A LOCATION
• Make sure that the speed of the wind at the location does not exceed 50km/hr.
• Put the light tower at the same level or at a higher level than the location to
be illuminated. This gives the best light coverage.
• Make sure that the location is clean and level with the ground. This will
decrease risk of injury to personnel, and risk of the light tower moving or
falling.
•
Make sure that the location is easy to access.
• The light tower mast can be raised to 24.5ft (7.5m). Make sure that the area
above the light tower is clear.
LIFTING
Lifting HiLight V3+ and HiLight V2+
• The lifting eye (LE) for the unit is above the engine.
• Use lifting and loading equipment, e.g. slings, hooks, chains, ramps, etc. of
the correct rating. The gross vehicle weight rating of the light tower is given
on its identification tag.
Lifting HiLight P2+
• Remove the Locking screw (LS) and bring the locking ring (SR) to the lowest
position. Do not re-fit the locking screw (LS).
• The Support legs (SL) are hinged to the connecting rod (CR) and the base of
the mast (M). The connecting rod (CR) in hinged to the locking ring (SR).
Fold the support legs (SL) up such that they touch the light tower mast (M).
Before using the HiLight V2+ or HiLight V3+ or HiLight P2+,
read the instruction manual carefully. Obey all instructions given
in the manual.
