- 21 -
• Refit the locking screw (LS) to the mast at the
closest position.
• Put the folded unit into its carry-case. Lift the
carry-case by hand.
Deployment of HiLight V3+ and HiLight V2+
Towing
1. Before towing
• Always tow the light tower when the mast is at
its lowest position.
• Attach a red flag on the top of the mast before
towing the light tower.
• Check tires for wear. Do not use worn out tires.
• Make sure that the tires are inflated to the
correct pressure.
• Make sure that the wheel lugs are tight.
• Make sure that the breaks are in good operating
condition.
• Make sure that the steering system is in good
operating condition.
2. During towing
• Do not load the unit with parts or tools.
• Do not tow light towers one after the other as a
group.
• Maximum permitted towing speed on the
highway is 45mph (72km/h). Maximum
permitted towing speed on rough land is 10mph
(16km/h).
• Follow all the applicable 'Department Of
Transportation' (DOT) regulations.
3. After Towing
• Press the foot break (FB) to prevent the unit
from moving.
• Set the hand break (HB) on the wheel to prevent
them from moving.
• Release the foot break (FB).
• Move the towing vehicle away from the unit.
CAUTION FOR LOCKING SCREW:
If care is not taken, the locking screw
(LS) can scratch the mast (M) or prevent
the inner mast from getting raised.
- To prevent scratches, do not let
the locking screw (LS) touch the
mast (M) while changing the
position of the locking ring (SR).
- Rotate the locking screw (LS) so
that it is inserted in the hole of the
outer mast (M) only. Always take
this precaution before running the
winch to prevent damage to the
inner mast and to make sure that
the inner mast can be raised.
Not refitting the locking screw (LS)
while transporting the folded HiLight
P2+ can lead to injury.
Before using the HiLight V2+ or HiLight
V3+, read the instruction manual
carefully. Obey all instructions given in
the manual.
