Atlas Copco LTV38 R Series User Manual

Safety Information LTV38 R..TS/..TAS
10
© Atlas Copco Industrial Technique AB - 9836 1857 00
The air pressure inside the tool is measured
through a small hose (see Optional accessories -
Kit RE-Signal) and converted into a digital signal.
This signal is processed in the RE-Controller. The
RE-Controller gives instant visual and audio feed-
back to the operator on whether the tightening was
OK or not OK.
For further information, please see leaflet 9833
1358 01.
Check of valve play
Valve play, L = xmm
Testing of tightening torque
Torque and angle testing instrument
ACTA* 3000/ 4000. For further informatiom,
please see our main catalogue or separate leaflet.
Testjoint and Transducer
Select testjoint and transducers according to maxi-
mum torque of your tool
Test joints - High torque range
Bolt size
Torqu
e
range
Nm
Order-
ing
No.
Torqu
e rate
Nm/
rev.
De-
grees
at
rated
capac-
ity
Ser-
vice
kit*
M8 15 4080
0788
91
10 540 4080
0788
80
Bolt size
Torqu
e
range
Nm
Order-
ing
No.
Torqu
e rate
Nm/
rev.
De-
grees
at
rated
capac-
ity
Ser-
vice
kit*
M10 30 4080
0789
91
24 450 4080
0789
80
M12 60 4080
0790
91
40 540 4080
0790
80
M14 90 4080
0791
91
60 540 4080
0791
80
M16 200 4080
0866
90
200 360 4080
0865
80
M20 400 4080
0868
90
400 360 4080
0867
80
M30 800 4080
0876
92
800 360 4080
0867
80
* Including 2x bolts, 2x nuts, 2x washers
In-line torque transducers – Torque
models
Model
Drive
Hex
inch
Drive
Squar
e inch
Rated
capac-
ity Nm ft lb
Order-
ing No
IRTT 5-
I06
¼ 5 4 8092
1129
05
IRTT 20-
I06
¼ 20 15 8092
1129
10
IRTT
20-06
¼ 20 15 8092
1129
15
IRTT
25-10
3/8 25 18 8092
1129
20
IRTT
75-10
3/8 75 55 8092
1129
25
