Page 12
Unity Controller R9 Variants, Issue 13
Variation R9 GLB
Part No 4222610001 4222622824 4222622826 4222624806
Thermostat
   
UL
   
CE
   
Mains Voltage 380-500VAC 380-500VAC 380-500VAC 380-500VAC
Fused Mains
   
Circuit Breakers Mains
Capacitor Module
   
BRF Power
600 x 600 Enclosure
   
800 x 600 Enclosure
BRF Bulkhead
Connections
External Comms
Bulkhead

Front Mounted
Disconnect
Side Mounted
Disconnect
   
20 A DC Power Supply
   
10A DC Power Supply
Key Switch
  
Selector Switch

40 Degrees C Ambient
45 Degrees C Ambient
   
Safety Type DualDry DualDry DualDry Dual Dry
Colour RAL9005 RAL9005 RAL9005 RAL9005
