Page 25
Unity Controller R9 Variants, Issue 13
9 Technical Data
9. 1 Controller Performance / Specication
Power consumption Application dependant
Operating conditions Application dependant
9. 2 HMI Performance / Specication
Display On board, high quality, colour touch-screen
Backup Automatically activated UPS with auto save data
Error Logging Continuous, for each joint produced
Event History Nominally, last 500 errors per tool
Interfaces 2 x Ethernet and 2 x USB
NOTE
No special tools required for maintenance of the Controller.
9. 3 Disposal
The Controller assembly contain electrical components. Dispose of the components responsibly
and in line with local/national environmental requirements and legislation.
It is the responsibility of the end user to dispose of the equipment. For reference, use the
Environmental Data Sheet provided.
