Vehicle Diagnosis And Adjustment 39
Atlas Cyclops
Press F4 in the technical data display phase (see part 9.4). The following
screen will be displayed:
Figure 2 6
To carry out the thrust out-of-center operation, it is recommended to carefully
follow the displayed instructions.
The starting point is acquired a little further ahead, so that it always remains
inside the tables also on the second point, thus avoiding any small gaps.
First position
on turn-tables,
approximately
15° forward
Vehicle
Starting
Point
Press F5 or
the central
key on one
of the two
cameras
