Vehicle Diagnosis And Adjustment 47
Atlas Cyclops
Figure 3 6
The vehicle can now be prepared for adjustment (see part 9.10), by pressing F4
to confi rm (Figure 36).
9.10 Adjustment Preliminary Operations
By selecting F4 from Figure 36 (see part 9.9), it is necessary to carry out
adjustment preliminary operations. Follow the displayed instructions to carry out
adjustment preliminary operations. Press F4 to continue.
Figure 3 7
1. Place steering wheel
in straight position.
2. Lock steering wheel
with steering lock
tool, and continue.
