Vehicle Diagnosis And Adjustment 51
Atlas Cyclops
Note: Steering level indicator is displayed only to give the operator a reference
of the value, which should remain within the maximum alignment reading range
(about 22÷24°).
After pressing F5, the page shown in Figure 41 will be displayed. “De-freeze”
to enable carrying out of partial toe-ins. Use F2
(LH partial toe-in) or F3
(RH partial toe-in).
When adjustment has been completed, press F1
to return to front
adjustment phase (part 9.12). The program will request to steer back toward
the center before the front adjustment page is displayed (Figure 39).
Figure 4 1
Detector Keypad Pc Keypad Description
It returns to front
adjustment page display.
It de-freezes / freezes
LH partial toe-in
It de-freezes / freezes
RH partial toe-in
To Next Page
