Atlas SUNTEST CPS+ User Manual

- 13 -
Operating Manual SUNTEST
®
CPS+
3
Description of the instrument
 Door lock switch
 Test chamber door
 Reector
 Sensor for measuring irradiance
 Air inlet for temperature regulation in the test
chamber
 Black standard sensor (BST)
 Sample table
3.3 Test chamber
• Door lock switch

for opening / closing the test
chamber door

• The reector

is located in the test chamber and in
the test chamber door. The xenon lamp is located in
the roof of the test chamber
• The sensor

to measure the irradiance (E)
• Black standard sensor (BST)

to measure the black
standard temperature at sample level
• Air inlet

for temperature control in the test chamber
• Sample table

used for positioning the samples
0
1
2
3
4
5
6
7
Fig. 3
