Operating Manual SUNTEST
®
CPS+
10
Technical Data
Incoming power:
Incoming power connection: (1P/N/PE) AC
Type E (16 A, 3 pole)
Nominal voltage/frequency: 230 V ± 10%
50 / 60 Hz
Nominal current: 14,5 A
Fuse: 16 A
Nominal power: max. 2,1 kVA
Nominal power of the xenon lamp: max. 1,5 kW
Light source:
Light source: 1 xenon lamp, air-cooled
Guaranteed life: 1500 hours
(1500 h at 65 W/m
2
@ 300 nm – 800 nm)
(1500 h at 65 W/m
2
@ 300 nm – 400 nm)
Distance from lamp axis to test plane: approx. 230 mm
Irradiance* at sample level:
* The values may uctuate depending on the age of
the lamp and test/laboratory conditions.
Black standard temperature:
Black standard temperature
on sample level up to 100 °C / ± 10%
(against ambient temperature)
Test chamber:
Available sample area: max. 560 cm²
Dimensions (W x D): 28 x 20 cm
Cooling air requirement:
Lamp unit max. 150 m
3
/h
Test chamber: min. 60 m³/h, max. 150 m³/h
Interface: RS232
Dimensions and weight:
Dimensions (W x D x H): 78 x 35 x 35 cm
Weight: approx. 30 kg
Ambient conditions:
Room temperature: 18 °C – 25 °C
Relative humidity: 50% (+/- 10%)
Air pressure: 700 – 1060 hPa
Noise Emission:
Noise level: max. 70 dB(A)
Filtering
Wavelength
range (nm)
Irradiance
(W/m
2
)
Daylight
reduced IR
300 – 400
300 – 800
30 – 65
250 – 765
Window glass
reduced IR
300 – 400
300 – 800
30 – 60
250 – 765
StoreLight
reduced IR
300 – 800 250 – 500
ID 65
reduced IR
300 – 400
300 – 800
20 – 50
250 – 500
Solar Standard
300 – 400
300 – 800
30 – 65
250 – 765
