Atmel ATmega8535L - Power-Save Supply Current

274
ATmega8535(L)
2502K–AVR–10/06
Figure 145. Power-Down Supply Current vs. V
CC
(Watchdog Timer Enabled)
Power-Save Supply Current Figure 146. Power-Save Supply Current vs. V
CC
(Watchdog Timer Disabled)
POWER-DOWN SUPPLY CURRENT vs. V
CC
WATCHDOG TIMER ENABLED
0
0.005
0.01
0.015
0.02
0.025
2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(mA)
85°C
25°C
-40°C
POWER-SAVE SUPPLY CURRENT vs. V
CC
WATCHDOG TIMER DISABLED
0
2
4
6
8
10
12
14
16
2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
25°C
