56
ATmega8535(L)
2502K–AVR–10/06
when resuming from the above mentioned sleep modes, as the clamping in these sleep
modes produces the requested logic change.
Unconnected pins If some pins are unused, it is recommended to ensure that these pins have a defined
level. Even though most of the digital inputs are disabled in the deep sleep modes as
described above, floating inputs should be avoided to reduce current consumption in all
other modes where the digital inputs are enabled (Reset, Active mode and Idle mode).
The simplest method to ensure a defined level of an unused pin, is to enable the internal
pull-up. In this case, the pull-up will be disabled during reset. If low power consumption
during reset is important, it is recommended to use an external pull-up or pull-down.
Connecting unused pins directly to V
CC
or GND is not recommended, since this may
cause excessive currents if the pin is accidentally configured as an output.
