Alternate Functions of Port C The Port C pins with alternate functions are shown in Table 29.
The alternate pin configuration is as follows:
• TOSC2 – Port C, Bit 7
Table 27. Overriding Signals for Alternate Functions in PB7..PB4
Signal
Name PB7/SCK PB6/MISO PB5/MOSI PB4/SS
PUOE SPE • MSTR SPE • MSTR SPE • MSTR SPE • MSTR
PUOV PORTB7 • PUD PORTB6 • PUD PORTB5 • PUD PORTB4 • PUD
DDOE SPE • MSTR SPE • MSTR SPE • MSTR SPE • MSTR
DDOV 0 0 0 0
PVOE SPE • MSTR SPE • MSTR
SPE • MSTR 0
PVOV SCK OUTPUT SPI SLAVE OUTPUT SPI MSTR OUTPUT 0
DIEOE 0 0 0 0
DIEOV 0 0 0 0
DI SCK INPUT SPI MSTR INPUT SPI SLAVE INPUT SPI SS
AIO – – – –
Table 28. Overriding Signals for Alternate Functions in PB3..PB0
Signal
Name PB3/OC0/AIN1 PB2/INT2/AIN0 PB1/T1 PB0/T0/XCK
PUOE 0 0 0 0
PUOV 0 0 0 0
DDOE 0 0 0 0
DDOV 0 0 0 0
PVOE OC0 ENABLE 0 0 UMSEL
PVOV OC0 0 0 XCK OUTPUT
DIEOE 0 INT2 ENABLE 0 0
DIEOV 0 1 0 0
DI – INT2 INPUT T1 INPUT XCK INPUT/ T0
INPUT
AIO AIN1 INPUT AIN0 INPUT – –
Table 29. Port C Pins Alternate Functions
Port Pin Alternate Function
PC7 TOSC2 (Timer Oscillator Pin 2)
PC6 TOSC1 (Timer Oscillator Pin 1)
PC1 SDA (Two-wire Serial Bus Data Input/Output Line)
PC0 SCL (Two-wire Serial Bus Clock Line)
