Atmel ATmega8535L - Standby Supply Current

275
ATmega8535(L)
2502K–AVR–10/06
Standby Supply Current Figure 147. Standby Supply Current vs. V
CC
(455 kHz Resonator, Watchdog Timer
Disabled)
Figure 148. Standby Supply Current vs. V
CC
(1 MHz Resonator, Watchdog Timer
Disabled)
STANDBY SUPPLY CURRENT vs. V
CC
455 kHz RESONATOR, WATCHDOG TIMER DISABLED
0
10
20
30
40
50
60
70
80
90
2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
STANDBY SUPPLY CURRENT vs. V
CC
1 MHz RESONATOR, WATCHDOG TIMER DISABLED
0
10
20
30
40
50
60
70
2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
