Atmel ATmega8535L - Current Consumption Of Peripheral Units

295
ATmega8535(L)
2502K–AVR–10/06
Current Consumption Of
Peripheral Units
Figure 187. Brownout Detector Current vs. V
CC
Figure 188. ADC Current vs. V
CC
(AREF = AVCC)
BROWNOUT DETECTOR CURRENT vs. V
CC
0
0.005
0.01
0.015
0.02
0.025
2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(mA)
85 °C
25 °C
-40 °C
ADC CURRENT vs. V
CC
AREF = AVCC
0
100
200
300
400
500
600
2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
85 °C
25 °C
-40 °C
