294
ATmega8535(L)
2502K–AVR–10/06
Figure 185. Calibrated 1 MHz RC Oscillator Frequency vs. V
CC
Figure 186. Calibrated 1 MHz RC Oscillator Frequency vs. Osccal Value
CALIBRATED 1 MHz RC OSCILLATOR FREQUENCY vs. V
CC
0.85
0.87
0.89
0.91
0.93
0.95
0.97
0.99
1.01
1.03
1.05
2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
F
RC
(MHz)
85 °C
25 °C
-40 °C
CALIBRATED 1 MHz RC OSCILLATOR FREQUENCY vs. OSCCAL VALUE
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
1.8
2
0 163248648096 112 128 144 160 176 192 208 224 240
OSCCAL VALUE
F
RC
(MHz)
