Atmel ATmega8535L - Current Consumption In Reset And Reset Pulsewidth

297
ATmega8535(L)
2502K–AVR–10/06
Figure 191. Programming Current vs. V
CC
Current Consumption In
Reset And Reset Pulsewidth
Figure 192. Reset Supply Current vs. V
CC
(0.1 - 1.0 MHz, Excluding Current Through
The Reset Pull-up)
PROGRAMMING CURRENT vs. V
0
2
4
6
8
10
12
2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(mA)
85 °C
25 °C
-40 °C
CC
RESET SUPPLY CURRENT vs. V
CC
0.1 - 1.0 MHz, EXCLUDING CURRENT THROUGH THE RESET PULLUP
0
0.5
1
1.5
2
2.5
3
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Frequency (MHz)
I
CC
(mA)
5.5V
5.0V
4.5V
3.3V
3.0V
2.7V
4.0V
