280
ATmega8535(L)
2502K–AVR–10/06
Figure 157. Reset Pull-up Resistor Current vs. Reset Pin Voltage (V
CC
= 5V)
Figure 158. Reset Pull-up Resistor Current vs. Reset Pin Voltage (V
CC
= 2.7V)
RESET PULL-UP RESISTOR CURRENT vs. RESET PIN VOLTAGE
Vcc = 5V
0
20
40
60
80
100
120
0123
V
RESET
(V)
I
RESET
(uA)
85°C
25°C-40°C
RESET PULL-UP RESISTOR CURRENT vs. RESET PIN VOLTAGE
Vcc = 2.7V
0
10
20
30
40
50
60
0 0.5 1 1.5 2 2.5 3
V
RESET
(V)
I
RESET
(uA)
85°C
25°C-40°C
