Atmos C 31 - Changing the Heating Coil of the Mirror Quick Heater

33
Fig. 37. Removing the heat
Fig. 36. Mirror quick-heater
 Grid
6.3 Changing the heating coil of the
mirror quick-heater

Grid and sleeve might get very hot. Allow them to cool
down before changing the heating coil !
 Set main switch of the ENT unit to OFF
(
,g.1,page7).
 Removegrid(,g.36).
 Pull out the heating coil (
,g.37)locatedunderthegrid
along with its plug connections.
 Insert a new heating coil and make sure that the three
heating helices come into contact only with their ends.
 Fix the grid again and set main switch to ON.


6.0 Maintenance and servicing
