5
1.4 Explanation of symbols
ON (power) as to
IEC 417/5007 and DIN 30600/16
OFF (power) as to
IEC 417/5007and DIN 30600/16
Pay attention to operating instructions !
as to ISO /7000/0434 DIN 30600/1008 IEC 348
Cold-light system
Warm water system
Cleaninginowprocedure(hoserinsing)
Microscope connection (cold light)
Suction system
Compressed-air system
Headlamp
Transfer of heat, in general;
mirror heater
Footswitch
Short-time operation
Protective earth (ground) as to
IEC 417/5019, DIN 30600/1545
Dangerous voltage as to
IEC 417/5036, DIN 30600/131
Fuse as to
IEC 417/5016, DIN 30600/0186
Type B equipment
Type BF equipment
(only for cold light)
~
Alternating current
On / Off switch
Basin rinsing
Water temperature for ear rinsing
too high
Water temperature for ear rinsing
too low
Correct water temperature for ear rinsing
Button for increasing lamp intensity
Button for decreasing lamp intensity
I
O
1.0 Introduction
Do not lean against it!
Danger of tilting for units with a
microscope!
Screw the unit into the ground
or position it near a wall.
060.0628.0
