Atomos SHOGUN User Manual

*Subject to change without notice Atomos Shogun – User Manual Edition 2: January 2016 43
Shogun specs
Specications correct at time of printing E&OE
SPECIFICATIONS
SHOGUN
Weight & dimensions
Without batteries & media
460g / 16oz
With batteries & media
732g / 26oz
Dimensions (W x H x D mm)
196x110x47mm,7.7x4.3x1.85”
Construction
High quality lightweight ABS Polycarbonate for
durability & portability
Power
Operating power
10 - 20W
Redundant PSU
NP series, D-Tap and supporting accessories
Compatible batteries
6.2V to 16.8V
Battery time (based on 7.4V)
-
5200mAh - up to 1.5hrs (monitor & record 4K)
7800mAh - up to 2.2hrs (monitor & record 4K)
DC Out
1 x DC in (6.2 - 16.8V)
Continuous power
* Patent pending
via optional Power Station
Touchscreen
Size
7.1”
Resolution
1920 x 1200
PPI
Over 320
Aspect ratio
16:9 native
Color standard
REC709 HDTV
Look up table (LUT) support
3DLUT(.cubeleformat)
Technology
SuperAtom IPS panel (capacitive touch), calibration
to Rec.709 with optional Atomos Spyder
Video analysis tools
Luma waveform, RGB parade, Vectorscope,
Vectorscope zoom
Calibration
CalibrationinfactorytoRec.709,ineld
calibration with optional Spyder
Video input/loop out
HDMI
1 x HDMI (1.4b)
SDI
1 x 4K-SDI 12G/6G or HD-SDI 3G/1.5G (SMPTE)
Signal
Uncompressed true 10-bit or 8-bit 422
(camera dependent)
Video output (play out)
HDMI
1 x HDMI (1.4b)
SDI
1x 4K-SDI 12G/6G or HD-SDI 3G/1.5G (SMPTE)
Signal
Uncompressed true 10-bit or 8-bit 422
(playbackledependent)
Supported formats (Record & Playback)
4K - DCI RAW 4096x2160 to
Supported cameras;
Sony FS700, FS7
CanonC300MKII,C500
Apple ProRes
HQ, 422, LT
DNxHR
HQX, HQ, SQ, LB
4K-UHD 3840x2160 8/10-bit 4:2:2 to
Apple ProRes
HQ, 422, LT
DNxHR
HQX, HQ, SQ, LB
1920x1080 8/10-bit 4:2:2 to
Apple ProRes
HQ, 422, LT
DNxHD
220x, 220, 145, 36
1280x720 8/10-bit 4:2:2 to
Apple ProRes
HQ, 422, LT
DNxHD
220x, 220, 145, 36
Onboard processing
Pulldown removal
24/25/30pSF > 24/25/30p (2:2 pulldown)
60i > 24p (3:2 pulldown)
HDMI < > SDI conversion
Yes - Always on
4K - UHD to HD downscale
On HDMI/SDI loop out (Rec & Playout)
SPECIFICATIONS
SHOGUN
Audio in/out (48kHz PCM audio)
HDMI
2 or 8ch 24-bit, camera dependent
SDI
12ch 48kHz 24-bit
Analogue audio
2 x XLR in & 2 x XLR out on rear per record
channel.
Mic or line level with phantom 48V
Processing
Gain control on line in & headphone output
Maximum audio quality
24-bit, 48kHz
Audio delay
Delay setting +1 to 99 frames
Remote control
HDMI
Auto HDMI Trigger
Supported Protocols - Canon, Sony, Atomos Open
Standard
SDI
SDI trigger camera selectable
RS422
-
AMP
-
Serial
-
Timecode
HDMI Embedded Timecode from camera or video device
SDI Embedded Timecode from camera or video device
LTC In Yes (LTC loop back)
GenLock In Yes (GenLock loop back)
Playback
Playlist
Yes (run down or reverse order) for selected, favorite
or all clips
Playback options
Loop in & out markers
Recording
Dual channel
-
Continuous record
-
Pre-roll record
Yes (HD 8s, 4K 2s)
Custom time lapse
Yes (Key frameable up to 10 video and single frame
Intervals, can be triggered from internal clock).
Meta data tagging
Yes (10 tags available)
Recording media
Drive slots 1
Drive connection types SATA
Supported media
(Approved List Only)
4K / HD (50/60/120p*)
CFast2.0,SSD2.5”,HDD(HD50/60only-7,200up
to 1080p60)
HD
CFast1.0,SSD2.5”,HDD(5,400upto1080p30)
Master caddy case
Master Caddy II (included)
75mm x 105mm x 12mm
Master caddy dock
2.5”SATAtoUSB2.0/3.0
Supported applications
FCPX/FCP7+ / Media Composer 5.0+ / Premiere 5.5+,
EDIUS 6.0+ / Vegas Pro 10+ / Lightworks / Autodesk
Smoke 2015
XMLsupport
FCPX XML native, FCP7 supported with conversion
(Adobe compatible)
Accessories included
Shogun unit, Custom HPRC Italian made carry case,
9V-3A AC adapter, Master Caddy II x 5, D-Tap adapter,
1 x 5200 mAh battery, Battery charger, XLR breakout
cable, SATA 3/2 to USB 3/2 HDD/SSD docking station
Optional extras
Sunhood, Power Station, Spyder calibration
Warranty
1 year. Extended to 3 years on product registration

Atomos SHOGUN Specifications

General

Display resolution	1920 x 1200 pixels
HDD size	2.5 \
HDD interface	Serial ATA
Power consumption (typical)	20 W
Product color	Black

Weight and Dimensions

Weight	732 g
Dimensions (WxDxH)	196 x 47 x 110 mm
