DLA2/4/6 Speaker Level Audio Router
Appendix A: Specifications
DLA2/4/6
Power Input +12 VDC, 2.1 Amps
Ampli er Impedance 4 - 8 Ohms
Speaker Impedance 4 - 8 Ohms
Frequency Response 20 HZ to 20 kHZ +/- 1 dB
Power Handling Per Channel: 125 Watts RMS
Max Attenuation -56 dB @ Last Step
Dynamic Range 43 dB over 12 steps
THD < 1%
Connections
Power 2.1 mm Jack
Ampli er Input 4 Position Flip-lock Connector
(16AWG Speaker Wire)
Speaker Output 4 Position Flip-lock Connector
(16AWG Speaker Wire)
Sense Inputs 2.1mm Jack
IR Input 4 Position Flip-lock Connector
Page/Doorbell Trigger In 3.5mm Mono Jack
IR Emitter Output 3.5 mm Mono jack
RF Input (ATON Port) RJ-11 jack
Dimensions
H x W x D (w/ feet)
DLA2
DLA4/DLA6
Unit Height w/ Feet
2 3/16" x 8 1/2" x 7 5/8"
(5.6cm x 21.6cm x 19.4cm)
2 3/16" x 17" x 8 5/8"
(5.6cm x 43.2cm x 21.9cm)
1 3/4" (4.5cm)
Weight
DLA2
DLA4
DLA6
4.95lbs (2.3kg) unit weight
5.7lbs (2.6kg) shipping weight
10.15lbs (4.6kg) unit weight
11lbs (5kg) shipping weight
12.15lbs (5.5kg) unit weight
13lbs (5.9kg) shipping weight
