DLA2/4/6 Speaker Level Audio Router
Appendix C: Remote Control Options
Option #1: DLA Slimline Remote (DLAIRM)
Any combination of DLA remote control options may be used on a single DLA2/4/6 system.
Use the included DLAIRM IR Remote Control to program DLA IR codes into a third-
party universal/learning remote.
Universal/Learning
IR Remote Control
DLAIRM
Figure C-1: Universal Remote
Use the DLAIRM as an IR remote for any individual room. Each room that is to be
controlled with the DLAIRM requires an IR receiver wired into that speci c room’s IR
Input as shown in Figure C-2.
IR Input
Cat-5
AIR5
DLAIRM
Figure C-2: DLAIRM as Room Controller
