Attacus AT-200 - Page 16

AT
14
Hex wrench
1) Get the front armrest set.
2) Insert screw through the front armrest retainer and vercal tube unit
bracket carefully, make sure screws are well posioned and parally
ghtened.
3) Repeat step 2 to secure right armrest unit bracket fixaon.
Hardware pack for step 4
QtyDescriponParts
A
TypeIllustraon
2
Socket Head Cap Bolt (16L) Screw
• Please assemble the console with great care. Make sure no wire is pressed or bent to avoid any damage.
• Please assemble the console with great care. Make sure no wire is pressed or bent to avoid any damage.
Step 4 of Assembly Procedure
