Section 5 Troubleshooting electric starting system
Remark
.Remove the following parts before troubleshooting
1)Cushion
2)Front frame
3)Front fender
.Use the following special tool to troubleshoot
6.Main switch
7.Neutral switch
8.Rear brake switch
9.Staring switch
10.Circuit connection(Whole starting system)
If starting motor doesn’t work
1.Safety
Refer to “check of switch”
Pass
Pass
2.Battery
.Check the battery condition
Refer to “check battery”in chapter 3
Voltage of open circuit
At 20¡æ(68¡ãF)12.8V or much more
3.Starting motor
.Connect positive terminal ¢Ùof battery with cable
¢Ú fo starting motor by wire ¢Û.
.Inspect the running condition of starting motor.
Pocket-multimeter
No electrification
.Clean the battey terminal
.Recharge or replace battery
Incorrect
Warning
.Jumper wire must have the same or bigger loading capa-
bility than battery wire, otherwise it would be burned.
.This kind of testing is similar to marking electric spark,
therefore, no inflammable air or liquid nearby must be
ensured.
-123-
