(II) Disassembly of engine

1.Remove

.Hand starting unit¢Ù

2.Remove

.Screw ¢Ù¢Ú¢Û

.Reverse controlling bar unit¢Ü

.Wahser

Pay attention not to lose washer

3.Remove

.Sproket cabinet cover ¢Ù

4.Remove

.Spark plug¢Ù

.Upper valve cap(intake)¢Ú

.Lower valve cap(exhaust)¢Û

¢Ù

¢Ú

¢Û

-145-
