5.Remove
.Chain tensioner¢Ú
Caution:
Before removing the chain tensioner, loosen
the screw ¢Ùfirstly.
6.Remove
.Bolt
Timing sproket
Caution:
.When loosening the bolt, it is needed to fix
the hand starting ratchet ¢Ü
.Grasp the metal wire ¢Ûto avoid the timing
chain to drop into crankcase.
7.Remove
.All the bolts and nut on the cylinder cover.
Caution:
Loosen every bolt and nut by1/4 circle, then
disassembly
.Loosen them, from big one to small one ac-
cording to the numbers marked on the cylin-
der cover.
8.Remove
.Cylinder cover unit ¢Ù
.Cylinder cover pad ¢Ú
.Location pin¢Û
.Oil seal¢Ü
.Lower guide plate ¢Ý(exhaust side)
¢Ù
¢Ú
¢Ù
¢Ú
¢Û
¢Ü
¢Ú
¢Ü
¢Ý
¢Þ
¢Û
¢Ù
¢Ù
¢Û
¢Û
¢Û
¢Ú
¢Ü
¢Ý
-146-
