ATV 250 - 1. Balance Shaft Gear and Driving Gear

1. Balance shaft gear and driving gear
1) Installment
¡¤Woodruff key ¢Ù
¡¤Driving gear of balance shaft ¢Ú
¡¤Circlip ¢Û
2) Installment:
¡¤Balance shaft gear ¢Ù (be driven)
¡¤Flat key ¢Ú
The mark ¢Ûof driving gear should align with
the mark of ¢Üdriven gear.
Caution
Use the gear puller.
Caution
3) Installment:
¡¤Locking washer ¢Ù
¡¤Nut ¢Ú(Dirven gear)
¡¤Be sure to use new locking washer.
¡¤Install the locking washer locating plate ¢Û
inside the key groove of balance shaft ¢Ü.
Caution
4) Tighten up:
¡¤Nut ¢Ù (Driven gear)
Place a fold cloth ¢Úbetween the balance shaft
gear ¢Û and the gear of driving gear ¢Üso as to
avoid turning of shaft, then tighten up the nut.
5) Bend the locking plate of locking washer.
Caution
¢Ü ¢Û
¢Ú
¢Ù
¢Ü
¢Û
¢Ù
¢Ü
¢Û
¢Ù
50N.m
¢Ú
¢Ú
