Multiformat switcher MS-8 Reference Manual
Parameter list
InputX (SDI)
InputX (SDI) 1/4
Parameter name Range Unit Remarks
Format
[InHsize]x[InVsize]/[InFrameRate][i/P/sF] Displays the input signal format.
Format Fix
Off
,On
When set to on, input format detection is disabled, and the input
format fixed.
Fix Format
2K/59p/50p/29p/25p/24p/23p,1080/59p/50
p/29p/25p/24p/23p,
1080/59i
/50i,
720/59p/50p,480/59i,576/50i
Sets the input format to be used.
LOS Threshold
0,,
5
,,10
Sets the threshold for loss-of-signal action.
The lower the value the higher the sensitivity, and the higher the
value the better the system will resist noise.
