Multiformat switcher MS-8 Reference Manual
System MENU 2/4
Parameter name Range Unit Remarks
LOS Mode
Color, Freeze
Sets the action initiated when the input signal is interrupted.
Color: Screen set to specified color.
Freeze: Last image prior to interruption is maintained as a static
image.
* Static image is cleared when input signal recovers.
No Signal Color
RESET
Sets the screen color (RGB) when the input signal is lost.
Press reset to restore the initial values.
Red 0,,
16
,,255 Adjusts red component. *3
Green 0,,
16
,,255 Adjusts green component. *3
Blue 0,,
16
,,255 Adjusts blue component. *3
LOS Mute Clear Delay 1
,,10 frame Sets the delay time for audio fade-in start after input signal recovers.
Panel Lock Off
,On,MENU Lock
Off: Panel operation is enabled.
On: Panel operation is disabled.
MENU Lock: Menu operation is disabled.
Settings become effective when you leave the MENU screen. Hold
ENTER and EXIT down simultaneously for a few seconds to turn the
Panel Lock off.
OSD Font Size Sel Small
,Medium,Large
Change the screen MENU font size.
Small and Medium settings are valid when output is 720p.
When output setting is SD, allways disp Small font size.
SDI Out Interlace Off
,On
Sets the SDI output to interlace format.
It is valid at output setting is 1080p.
*3 Settings outside the 16-235 range may cause misoperation.
To Next Page
