Multiformat switcher MS-8 Reference Manual
Parameter name Range Unit Remarks
USB3.0 Settings
RESET
USB 3.0 output settings.
Press reset to restore the initial values.
USB OSD Off,
On
When on, displays the onscreen menu in USB 3.0 output.
USB Audio Level -INF,,
0.0
,,6.0 dB Adjusts the USB 3.0 output audio level.
Output MENU 2/4
Parameter name Range Unit Remarks
Output Zoom
RESET
Sets the scale (magnification) for output video.
Press reset to restore the initial value.
Zoom 10,,
100
,,1000 %
Adjusts horizontal and vertical scales while maintaining the aspect
ratio. *1
H position -[OutHsize],,
0
,,[OutHsize] pixel Adjusts the output video horizontal position. *2
V position -[OutVsize],,
0
,,[OutVsize] line Adjusts the output video vertical position *2
*1 The maximum zoom is 12 times of the total processed pixel equivalent.
The minimum zoom is 1/12th of the total processed pixel equivalent.
*2 Adjustment is limited by the e󰀨ective region.
