Multiformat switcher MS-8 Reference Manual
TELNET commands
Command list
Set Command
Input Format Fix
FMF:a,b,c<CR>
a:
Input Channel
0:IN1, 1:IN2, 2:IN3, 3:IN4, 4:IN5, 5:IN6, 6:IN7, 7:IN8
b:
Format Fix
0:O󰀨, 1:On
c:
Fix Format
<gure.1>
Analog Input Color
FCS:a,b<CR>
a:
Input Channel
4:IN5, 5:IN6
b:
Color Space
0:Auto, 1:RGB, 2:YCC(SD), 3:YCC(HD)
Analog Input Timing Adjust
ATA:a,b,c,d,e<CR>
a:
Input Channel
4:IN5, 5:IN6
b:
H position
-100,,100 pixel
c:
V position
-100,,100 line
d:
Frequency
-100,,100 pixel
e:
Phase
-16,,16
NTSC Input Setup Level
NSL:a,b<CR>
a:
Input Channel
6:IN7, 7:IN8
b:
NTSC Setup Level
0:0IRE, 1:7.5IRE
HDMI Input Color
HDC:a,b<CR>
a:
Input Channel
2:IN3, 3:IN4
b:
Color Space
0:Auto, 1:RGB(Full), 2:RGB(Limit), 3:YCC(SD), 4:YCC(HD)
Input LOS Threshold
LTH:a,b<CR>
a:
Input Channel
0:IN1, 1:IN2, 2:IN3, 3:IN4, 4:IN5, 5:IN6, 6:IN7, 7:IN8
b:
LOS Threshold
0,,10
Input AOI
AOI:a,b,c,d,e<CR>
a:
Input Channel
0:IN1, 1:IN2, 2:IN3, 3:IN4, 4:IN5, 5:IN6, 6:IN7, 7:IN8
b:
H size
0,,[InHsize] pixel
c:
V size
0,,[InVsize] line
d:
H position
0,,[InHsize-1] pixel
e:
V position
0,,[InVSize-1] line
