Multiformat switcher MS-8 Reference Manual
<gure.1> Input Format Fix Table
value IN1, IN2 IN3, IN4 IN5, IN6 IN7, IN8
0
2K/59p 2K/59p 2K/59p NTSC
1
2K/50p 2K/50p 2K/50p PAL
2
2K/29p 2K/29p 2K/29p -
3
2K/25p 2K/25p 2K/25p -
4
2K/24p 2K/24p 2K/24p -
5
2K/23p 2K/23p 2K/23p -
6
1080/59p 1080/59p 1080/59p -
7
1080/50p 1080/50p 1080/50p -
8
1080/29p 1080/29p 1080/29p -
9
1080/25p 1080/25p 1080/25p -
10
1080/24p 1080/24p 1080/24p -
11
1080/23p 1080/23p 1080/23p -
12
1080/59i 1080/59i 1080/59i -
13
1080/50i 1080/50i 1080/50i -
14
720/59p 720/59p 720/59p -
15
720/50p 720/50p 720/50p -
16
480/59i 480/59p 480/59p -
17
576/50i 576/50p 576/50p -
18
- 480/59i 480/59i -
19
- 576/50i 576/50i -
