Multiformat switcher MS-8 Reference Manual
System MENU
System MENU 1/4
Parameter name Range Unit Remarks
Sync Reference Internal
,REF IN,IN1,IN2
Selects synch signal.
REF IN: Synchs to the synch signal input to the REF IN connector.
IN1: Synchs to video input to SDI IN1.
IN2: Synchs to video input to SDI IN2.
H Phase -[OutHcycle]/2,,
0
,,[OutHcycle]/2 pixel Adjusts SDI output horizontal position relative to synch signal.
V Phase -[OutVcycle],,
0
,,[OutVcycle] line Adjusts SDI output vertical position relative to synch signal.
Transition Time
0,,
1.0
,,4.0 sec Sets the fade-in/fade-out time for video transitions.
Transition Color
RESET
Sets the RGB values for the screen inserted during video transitions.
Press reset to restore the initial value.
Red 0,,
16
,,255 Adjusts red component. *3
Green 0,,
16
,,255 Adjusts green component. *3
Blue 0,,
16
,,255 Adjusts blue component. *3
REF IN
----/Unlock/Lock Displays the synch state.
*3 Settings outside the 16-235 range may cause misoperation.
