Multiformat switcher MS-8 Reference Manual
Browse...button
Select the desired update file.
Update File
Displays the selected update file.
Now Version
Displays the versions of installed
programs.
Update Version
Displays the versions of the selected update files.
Exit button
Exist the Software Update screen.
UPdate Execute button
Update the software.
Parameter name
Display parameter groups and
parameter names.
The selected item is highlighted.
Parameter value
Display the parameter value.
Exit button
When top level is selected:
Exits the Parameter Setting screen.
When parameter name or value selected:
Move up one level.
Up button, Down button
When a parameter name is selected: Select an item.
When a parameter value is selected: Select the value.
Enter button
When a parameter group is selected: Move down one level.
When a parameter name is selected:
Edit the parameter value.
When a parameter value is selected: Move up one level.
Network remote
System requirements
Supported browsers
Windows
Google Chrome Version 50.0 for Windows
Microsoft Internet Explorer for Windows 7 Version 11.0
Microsoft Edge for Windows 10 Version 25
Mac Apple Safari for OS X Version 9.0.3
Refer to the Start Up Manual for information on connection the device to the network.
Start Up Manual Refer to Other connections
Browser connection
1
Use a browser on a PC running on the same network.
2
Connect the browser to the device using the IP address (http://192.168.1.1).
The network remote set-up screen will be displayed.
If the device is not displayed, check the network connections and IP address.
Refer to the parameter list for information on setting content and items.
Refer to P.13 Parameter list
Refer to P.31 IP Adress
Start Up Manual Refer to Other connections
