Multiformat switcher MS-8 Reference Manual
InputX (VIDEO)
InputX (VIDEO) 1/3
Parameter name Range Unit Remarks
Format
NTSC/PAL Displays the input signal format.
Format Fix
Off
,On
When set to on, input format detection is disabled, and the input
format fixed.
Fix Format
NTSC
,PAL Sets the input format to be used.
NTSC Setup Level
0IRE
,7.5IRE Selects the NTSC set-up level.
LOS Threshold
0,,
5
,,10
Sets the threshold for loss-of-signal action.
The lower the value the higher the sensitivity, and the higher the
value the better the system will resist noise.
InputX (RGB) 3/3
Parameter name Range Unit Remarks
Color Correct
RESET
Adjusts the input video color.
Press reset to restore the initial value.
Brightness 0,,
100
,,200 % Adjusts the brightness.
Contrast 0,,
100
,,200 % Adjusts the contrast.
Saturation 0,,
100
,,200 % Adjusts the saturation.
Red Brightness 0,,
100
,,200 % Adjusts the black balance (red).
Green Brightness 0,,
100
,,200 % Adjusts the black balance (green).
Blue Brightness 0,,
100
,,200 % Adjusts the black balance (blue).
Red Contrast 0,,
100
,,200 % Adjusts the white balance (red).
Green Contrast 0,,
100
,,200 % Adjusts the white balance (green).
Blue Contrast 0,,
100
,,200 % Adjusts the white balance (blue).
