Multiformat switcher MS-8 Reference Manual
Input Scaling
SCL:a,b,c,d,e,f,g<CR>
a:
Input Channel
0:IN1, 1:IN2, 2:IN3, 3:IN4, 4:IN5, 5:IN6, 6:IN7, 7:IN8
b:
Scaling Type
0:Full, 1:Box, 2:Crop, 3:Thru, 4:Manual
c:
Zoom
10,,1000 %
d:
H position
-2048,,2048 pixel
e:
V position
-1200,,1200 line
f:
Manual H scale
10,,1000 %
g:
Manual V scale
10,,1000 %
Input Color
IBC:a,b,c,d<CR>
a:
Input Channel
0:IN1, 1:IN2, 2:IN3, 3:IN4, 4:IN5, 5:IN6, 6:IN7, 7:IN8
b:
Brightness
0,,200 %
c:
Contrast
0,,200 %
d:
Saturation
0,,200 %
Input Black Balance
ICB:a,b,c,d<CR>
a:
Input Channel
0:IN1, 1:IN2, 2:IN3, 3:IN4, 4:IN5, 5:IN6, 6:IN7, 7:IN8
b:
Red Brightness
0,,200 %
c:
Green Brightness
0,,200 %
d:
Blue Brightness
0,,200 %
Input White Balance
ICC:a,b,c,d<CR>
a:
Input Channel
0:IN1, 1:IN2, 2:IN3, 3:IN4, 4:IN5, 5:IN6, 6:IN7, 7:IN8
b:
Red Contrast
0,,200 %
c:
Green Contrast
0,,200 %
d:
Blue Contrast
0,,200 %
Input Audio
AUD:a,b,c,d<CR>
a:
Input Channel
0:IN1, 1:IN2, 2:IN3, 3:IN4
b:
Audio Follow
0:O󰀨, 1:On
c:
Channel Select
0:1+2, 1:3+4, 2:5+6, 3:7+8, 4:9+10, 5:11+12, 6:13+14, 7:15+16 ch
d:
Channel Level
0:-INF,,127:6.0dB <gure.2>
