Multiformat switcher MS-8 Reference Manual
Ext Audio Input
EAI:a,b,c,d,e<CR>
a:
Stereo
0:Mono, 1:Stereo
b:
Mode
0:Audio Input, 1:GPI Input1-4, 2:GPI Output1-4
c:
Input Gain
0:-13.5,,63:+33.75 dB (+0.75 dB step)
d:
Audio Follow
0:O󰀨, 1:IN1, 2:IN2, 3:IN3, 4:IN4, 5:IN5, 6:IN6, 7:IN7, 8:IN8
e:
Input Impedance
0:Hi-Z, 1:600ohms
Output Format
OFT:a<CR>
a:
Format
0:2K/59p, 1:2K/50p, 2:2K/29p, 3:2K/25p, 4:2K/24p, 5:2K/23p, 6:1080/59p,
7:1080/50p, 8:1080/29p, 9:1080/25p, 10:1080/24p, 11:1080/23p, 12:1080/59i,
13:1080/50i, 14:720/59p, 15/720/50p, 16:480/59p, 17:576/50p, 18:480/59i,
19:576/50i
SDI Output Setting
SDI:a,b,c<CR>
a:
SDI OSD
0:O󰀨, 1:On
b:
SDI Color
0:YCC422, 1:RGB444, 2:YCC444
c:
3G SDI Type
0:LevelA, 1:LevelB
HDMI Output Setting
HDM:a,b,c,d<CR>
a:
HDMI OSD
0:O󰀨, 1:On
b:
HDMI Mode
0:Auto, 1:HDMI, 2:DVI(No Audio)
c:
HDMI Color
0:Auto, 1:RGB(Full), 2:RGB(Limit), 3:YCC444, 4:YCC422
d:
Color Depth
0:Auto, 1:8bit, 2:10bit
USB3.0 Output Setting
USB:a,b<CR>
a:
USB OSD
0:O󰀨, 1:On
b:
Audio Level
0:-INF,,100:0.0dB <gure.2>
Output Zoom
OPZ:a,b,c,d<CR>
a:
H Zoom
10,,1000 %
b:
V Zoom
10,,1000 %
c:
H position
-[OutHsize],,[OutHsize] pixel
d:
V position
-[OutVsize],,[OutVsize] line
Output Color
OBC:a,b,c<CR>
a:
Brightness
0,,200 %
b:
Contrast
0,,200 %
c:
Saturation
0,,200 %
