Multiformat switcher MS-8 Reference Manual
Output Black Balance
OCB:a,b,c<CR>
a:
Red Brightness
0,,200 %
b:
Green Brightness
0,,200 %
c:
Blue Brightness
0,,200 %
Output White Balance
OCC:a,b,c<CR>
a:
Red Contrast
0,,200 %
b:
Green Contrast
0,,200 %
c:
Blue Contrast
0,,200 %
Output Audio
OAU:a,b<CR>
a:
Mute
0:O󰀨, 1:On
b:
Delay
0,,100 msec
Ext Audio Output
EAO:a,b,c<CR>
a:
Mode
0:Audio Output, 1:GPI Input5-8, 2:GPI Output5-8
b:
Max Output Level
0:+24,,24:0 dBu (-1.0 dBu step)
System Sync Reference
SSR:a,b,c<CR>
a:
Sync Reference
0:Internal, 1:REF IN, 2:IN1, 3:IN2
b:
H Phase
-[OutHcycle]/2,,[OutHcycle]/2 pixel
c:
V Phase
-[OutVcycle],,[OutVcycle] line
System Transition Time
STT:a<CR>
a:
Transition Time
0.0,,4.0 sec
System Transition Color
STC:a,b,c<CR>
a:
Red
0,,255
b:
Green
0,,255
c:
Blue
0,,255
System LOS Mode
SLM:a<CR>
a:
LOS Mode
0:Color, 1:Freeze
System No Signal Color
SNS:a,b,c<CR>
a:
Red
0,,255
b:
Green
0,,255
c:
Blue
0,,255
