ATV MS-8 - Page 15

15
Multiformat switcher MS-8 Reference Manual
InputX (SDI) 3/4
Parameter name Range Unit Remarks
Color Correct
RESET
Adjusts the input video color.
Press reset to restore the initial value.
Brightness 0,
,100,
,200 % Adjusts the brightness.
Contrast 0,
,100,
,200 % Adjusts the contrast.
Saturation 0,
,100,
,200 % Adjusts the saturation.
Red Brightness 0,
,100,
,200 % Adjusts the black balance (red).
Green Brightness 0,
,100,
,200 % Adjusts the black balance (green).
Blue Brightness 0,
,100,
,200 % Adjusts the black balance (blue).
Red Contrast 0,
,100,
,200 % Adjusts the white balance (red).
Green Contrast 0,
,100,
,200 % Adjusts the white balance (green).
Blue Contrast 0,
,100,
,200 % Adjusts the white balance (blue).
InputX (SDI) 4/4
Parameter name Range Unit Remarks
Audio
Audio Follow Off,
On
Selects the audio selection method.
Off: Output at the set mixing level at all times.
On: Output at the set mixing level only when a video is selected.
Channel Level -INF,,
0.0
,,+6.0 dB Adjusts the mixing level.
Channel Select
1+2
,,15+16 Selects two channels from multi-channel (1–16).
