Note: This checklist is only for the standard factory configuration
Operation steps
1. Connect the circuit between the laser, the controller, and the galvanometer
driver. Connect the power cable. For the wiring method, refer to the
electrical control section of the user manual.
2. After getting the laser welding head, connect the optical fiber connector
first, and then connect the air pipe, water pipe and switch circuit.
(Thedetailed installation method of each connector is described later)
3. Turn on the power of the controller and wait for the screen of the laser
controller to start up, then turn on the laser switch and the water cooler
switch.
4. Set the relevant values on the controller screen (refer to the <User Manual
Electric Control Part> to set various parameters)
5. Put on goggles, hold the welding head with the welding head facing the
metal welding piece, and observe whether there is red light at the copper
nozzle of the welding head. If there is no red light, check whether the laser
emits light normally.
* Note: Observe the red light from the side of the welding head, and it is
strictly forbidden to look directly at the laser beam with your eyes.
6. Place the welded parts in the proper position. Adjust the angle of the
welding head to make the red light shine on the seam to be welded. Let the
