4. Wire feeder and welding machine connection installation
instructions
Steps for using with the welding machine
1、Connect the wire guide tube to the wire guide tube interface of the laser welding automatic
wire feeder. Tighten the wire outlet screw of the wire feeder and fix the wire inlet of the wire guide
tube.
2、Correctly connect the gun switch signal line input to the wire feeder
3、Correctly fix the wire guide tube on the laser welding gun and install the straight wire guide
tube.
5. Installation of welding wire
1、Connect the laser welding automatic wire feeder to the 24V switching power supply.
2、Put the welding wire reel on the inner reel shaft of the wire filling machine.
3、Select the groove diameter of the wire feed wheel, loosen the pressure regulator of the wire feeder,
pass the welding wire through the wire guide nozzle, and align it with the groove of the wire feed
wheel, and tighten the pressure regulator.
4、Press the spot wire feed switch on the panel/press the welding gun switch to send the welding
