7
Figure 2 - Structure of HW980
⚫ QBH connector: Complete the access and lock of the optical fiber
connector.
⚫ Collimating lens: Complete the fiber collimation function and collimate
the incident laser into a parallel beam.
⚫ Galvo-lens module: A component composed of a reflector and a motor is
used to vibrate and reflect the collimated parallel laser at a certain
angle，changing the direction of the original beam and the shape of
the spot.
⚫ Wi-remote module: Quickly adjust some using parameters.
